| Product Name | Round led panel light | |||||||
| Model | BY-SRP | |||||||
| Power | 3W | 4W | 6W | 9W | 12W | 15W | 18W | 24W |
| LED Type | SMD 2835 | |||||||
| LED Qty | 15pcs | 20pcs | 30pcs | 45pcs | 60pcs | 75pcs | 90pcs | 120pcs |
| Luminous Flux | 210lm±5% | 280lm±5% | 420lm±5% | 630lm±5% | 840lm±5% | 1050lm±5% | 1260lm±5% | 1680lm±5% |
| Dimension(mm) | φ90 | φ110 | φ120 | φ150 | φ170 | φ190 | φ225 | φ300 |
| Cut Size(mm) | φ70±5 | φ90±5 | φ100±5 | φ130±5 | φ150±5 | φ170±5 | φ200±5 | φ275±5 |
| Volume/Carton | 100 | 60 | 60 | 40 | 40 | 30 | 30 | 20 |
